Cyanoacrylate Adhesives-Selector Guide

This table represents a segment of Permabond’s complete line of cyanoacrylate adhesives. Contact the technical representatives at Permabond to discuss your specific application requirements. They will be able to recommend the most suitable adhesive for your application.

Contact us for more information

Grade (Click grade number for TDS) Description Viscosity mPa.s (cP) Shear Strength MPa (psi) Availability
101 General purpose, wicking type, plastic bonding 2-3 19-23 (2800-3300) Worldwide
102 General purpose, plastic bonding 70-90 19-23 (2800-3300) Worldwide
105 General purpose, elastomer bonding 30-50 18-22 (2600-3200) Worldwide
108 Intermediate gap fill, plastic bonding 400-600 20-22 (2900-3200) Americas & Asia
170 Metal bonding, maximum gap fill 1000-2000 23-25 (3300-3600) Americas & Asia
240 Plastic bonding, maximum gap fill and flow control 1200-2500 21-25 (3000-3600) Worldwide
268 Fast curing, intermediate gap fill 1200-2400 20-22 (2900-3200) Americas & Asia
731 Fast curing, maximum gap fill 100-200 24-30 (3500-4400) Worldwide
735 Toughened with high peel, impact and shear strength 100-200 24-30 (3500-4400) Worldwide
737 Toughened with high peel, impact and shear strength 2000-4000 19-23 (2800-3300) Worldwide
790 Surface insensitive, extremely fast curing, wicking type 1-3 18-22 (2600-3200) Americas & Asia
791 Surface insensitive, extremely fast curing, close fitting parts 30-50 18-22 (2600-3200) Worldwide
792 Surface insensitive, extremely fast curing, close fitting parts 60-125 18-22 (2600-3200) Worldwide
795 Surface insensitive, extremely fast curing, general purpose 400-600 18-22 (2600-3200) Americas & Asia
801 High temperature resistant to 130°C, wicking type 10-15 19-23 (2800-3300) Worldwide
802 High temperature resistant to 160°C 90-110 19-23 (2800-3300) Worldwide
820 High temperature resistant to 200°C 90-110 19-23 (2800-3300) Worldwide
2010 Thixotropic gel, maximum gap fill 10,000-20,000 Thixotropic 19-23 (2800-3300) Worldwide
2011 Thixotropic gel, non-sag, surface insensitive Gel 20-24 (2900-3500) Worldwide
910 General purpose, metal bonding 70-90 23-29 (3300-4200) Worldwide
910FS Metal bonding, wicking type 1-5 23-29 (3300-4200) Americas & Asia
919 Wicking type, high temperature resistant to 250°C 2-4 20-22 (2900-3200) Americas & Asia
920 General purpose, high temperature resistant to 250°C 70-90 19-23 (2800-3300) Worldwide
922 Maximum gap fill, high temperature resistant to 250°C 1200-2000 19-23 (2800-3300) Americas & Asia
940 Low odor & low bloom, wicking type 3-10 16-20 (2300-2900) Worldwide
941 Low odor & low bloom; close fitting parts 10-20 16-20 (2300-2900) Worldwide
943 Low odor & non-blooming; general purpose 90-110 16-20 (2300-2900) Worldwide
947 Low odor & low bloom; gap fill 900-1500 16-20 (2300-2900) Worldwide
POP Polyolefins primer 1 - 3 N/A Worldwide
QFS16 Cyanoacrylate accelerator 1 - 3 N/A Americas & Asia
CSA-NF Non-flammable CA accelerator 1 - 3 N/A Worldwide
CSA CA accelerator 1 - 3 N/A Worldwide

Contact us for more information
